首頁 > 產品展示 > 鎖緊盤聯軸器 > AS-23型

產品展示

風電鎖緊盤

液壓鎖緊盤

HYD-22型

鎖緊盤(收縮盤)

脹套(脹緊套)

脹套(新型)

聯軸器

凸輪逆止器

緊定套

退卸套

鎖緊螺母

法蘭聯軸器

鎖緊盤聯軸器

萬向節聯軸器

鎖緊墊圈

KM型

產品

鎖緊盤聯軸器系列

AS-23型

鎖緊盤聯軸器

產品概述
詳細參數
文檔下載

產品簡介

•23系列用于傳輸非常大的轉矩和彎曲力矩。

適用場景

軸的直徑從40mm到440mm，可傳輸?shù)霓D(zhuǎn)矩從1.4KNM到562KNM.

外形尺寸

AS23系列	基本參數									螺栓		重量
型號	dw	Mt	A	D	I	h	C	d1	d2	數量與規格	擰緊力矩	Weight
Type	mm	Nm	mm	mm	mm	mm	mm	mm	mm		Nm	kg
AS 50-23	50	3,300	84	115	29	30	3	58	53	7-M12	100	2.0
	45	2,200
	40	1,400
AS 60-23	60	4,700	94	120	32	34	3	66	63	9-M12	100	2.2
	55	3,500
	50	2,300
AS 70-23	70	9,400	112	148	38	40	4	79	74	8-M16	240	4.7
	65	7,600
	60	5,800
AS 80-23	80	12,000	130	170	42	44	4	94	84	9-M16	240	6.1
	75	10,000
	70	8,000
AS 90-23	90	18,000	144	185	48	50	4	104	94	12-M16	240	8.0
	85	15,000
	80	12,000
AS 100-23	100	23,000	156	197	52	54	4	114	104	14-M16	240	9.5
	95	19,000
	90	16,000
AS 110-23	110	27,000	166	215	56	58	5	124	116	10-M20	470	12.1
	105	26,000
	100	22,000
AS 120-23	120	43,000	186	230	62	65	5	134	126	14-M20	470	15.3
	115	38,000
	110	33,000
AS 140-23	140	56,000	216	290	73	76	5	160	146	16-M20	470	30.0
	130	50,000
	120	39,000
AS 160-23	160	77,000	234	320	80	83	5	180	166	14-M24	820	39.1
	150	77,000
	140	64,000
AS 180-23	180	104,000	276	340	91	94	5	205	186	16-M24	820	47.9
	170	101,000
	160	85,000
AS 200-23	200	144,000	290	370	95	96	5	226	206	16-M27	1210	57.0
	190	133,000
	180	114,000
AS 220-23	220	178,000	320	405	98	100	5	246	226	18-M27	1210	70.8
	210	178,000
	200	159,000
AS 240-23	240	211,000	340	430	109	110	5	266	246	20-M27	1210	85.8
	230	211,000
	220	211,000
AS 260-23	260	232,000	356	460	123	124	5	288	286	21-M27	1210	109.4
	250	234,000
	240	234,000
AS 280-23	280	234,000	360	485	128	130	5	304	306	21-M27	1210	125.0
	270	234,000
	260	234,000
AS 300-23	300	247,000	380	520	128	130	5	328	330	21-M27	1210	144.0
	290	247,000
	280	247,000
AS 320-23	320	299,000	402	550	134	136	8	348	350	24-M27	1210	167.0
	310	299,000
	300	299,000
AS 340-23	340	315,000	424	570	140	143	8	368	370	24-M27	1210	183.0
	330	315,000
	320	315,000
AS 360-23	360	410,000	454	610	144	147	8	398	400	24-M30	1640	218.0
	350	410,000
	340	410,000
AS 390-23	390	439,000	486	630	164	167	8	428	430	24-M30	1640	250.0
	380	439,000
	360	439,000
AS 420-23	420	457,000	506	670	172	175	10	448	450	24-M30	1640	292.0
	410	457,000
	390	457,000
AS 440-23	440	562,000	534	700	172	175	10	468	470	28-M30	1640	318.0
	420	562,000
	400	562,000
